What is HDMI 2.1a and why it matters for integrators

Key features of HDMI 2.1a

The latest upgrade to HDMI standards can serve higher resolutions with lower latency, thanks to these key features.

Bandwidth and Fixed Rate Link

Signalling technology fixed rate link (FRL) helps to achieve higher uncompressed resolutions above 4k60, as well as high-speed bandwidths up to 48Gbps. Prior to this, Transition Minimised Differential Signalling (TMDS) was used, which could only deliver 18Gbps.

HDMI 2.1a is versatile, supporting six fixed data rate tiers (9, 18, 24, 32, 40 and 48Gbps). In turn, this improves data transmission efficiency by 11% (80% in HDMI 2 to 89%). It also reduces signal interference with advanced equalisation and error correction. Users benefit from uninterrupted gameplay and razor-sharp imagery.

High Dynamic Range (HDR) and Source-Based Tone Mapping

Dynamic HDR optimises each image scene by scene, resulting in enhanced colour contrast for a lifelike, immersive experience. This produces broader colour palettes, while Source-Based Tone Mapping (SBTM) lessens display latency.

Tone mapping adjusts brightness levels to the capabilities of the device. When it’s source-based, it allows the device to instruct how tones should be mapped. This avoids visual inaccuracies such as too dull or bright images.

Gaming features

Gamers will love the uninterrupted thrills that come with Variable Refresh Rate (VRR). This means that the display technology refreshes visuals based on the frame rate of the device, which avoids screen tearing and other obstacles.

HMDI 2.1a also benefits from Auto Low Latency Mode (ALLM). This activates gaming mode on compatible devices like smart TVs, leading to faster response times and better gameplay.

Quick Frame Transport and Quick Media Switching

When refresh rates change, Quick Media Switching (QMS) stops screen flicker. Again, this provides uninterrupted gaming or a smoother viewing experience.

Response times are also quicker thanks to Quick Frame Transport (QFT). This reduces the rate of frame transmission, so that latency is lower when high-quality media is being delivered. In both cases, we see fewer instances of blank screens, and totally uninterrupted media.

System design considerations for HDMI 2.1a

Integrators need to consider the following design caveats when installing HDM1 2.1a:

Compatibility of devices

Your client’s devices will need to have supported formats. Check the product specifications for maximum bandwidth and features like VRR, QFT and dynamic HDR.

Cable selection

2.1a HDMI cables need to be ultra high-speed to support 48Gbps data rates. Ensure they are certified anti-counterfeit for quality and to avoid signal degradation.

Link training

You can use automated testing to check optimal data rates for the best performance. Be mindful that older components may impede overall performance.

Intermediate devices

Linked components such as extenders, switches and repeaters must support HDMI 2.1a features. Check this to avoid delays to high-bandwidth video.

Overcoming installation challenges

There may be additional installation challenges when we consider HMDI 2.1 vs 2.1a. We can overcome them by:

·        Electromagnetic interference (EMI): Shielding and enhanced error correction in ultra high-speed HDMI cables, or using shorter cable lengths where possible.

·        Enhanced Audio Return Channel (eARC): Using this technology improves high bandwidth audio transmission. It also supports high-resolution, immersive formats such as Dolby Atmos and DTS:X.

·        Troubleshooting tools: Using dedicated testing instruments can check bandwidth capabilities and signal integrity. You can also refer to the CEDIA/CTA-RP28 guidelines for system design and fault diagnostics.

Future-proofing HDMI installations

To keep customers satisfied and ahead of the curve with new HDMI, consider future upgrades. For example, you can install OM3 fibre as well as modular, adaptable system components that will support new formats.

These components must be reliable. This includes authenticity-certified cables from reputable manufacturers, which prioritise compatibility. Look for features like compression for ultra-high definition (UHD) formats.

Finally, it’s important to stay educated. You can continuously update your knowledge on HDMI versions with training from CEDIA, helping to anticipate client needs.
